There are several different types of ocean freight shipping containers. See the charts below for their dimensions:
Container Type (Feet/Inches) |
Number of Pallets w/Dimensions |
Door Openings (Feet/Inches) |
Internal Container Dimensions (Feet/Inches) |
Volume (ft3) |
|||
Width | Height | Length | Width | Height | |||
20 standard 20’x8’x8’6″ |
9 pallets – 1.2×1.0m | 7′ 8 1/16″ | 7′ 5 1/2″ | 19′ 4 1/8″ | 7′ 8 1/2″ | 7′ 10 3/16″ | 1,165 |
11 pallets – 1.2×0.8m | |||||||
40 standard 40’x8’x8’6″ |
21 pallets – 1.2×1.0m | 7′ 8 1/8″ | 7′ 5 1/2″ | 39′ 5 11/16″ | 7′ 8 1/2″ | 7′ 10 3/16″ | 2,366 |
25 pallets – 1.2×0.8m | |||||||
40 high 40’x8’x9’6″ |
21 pallets – 1.2×1.0m | 7′ 8 1/8″ | 8′ 5 7/16″ | 39′ 5 11/16″ | 7′ 8 1/2″ | 8′ 10 1/8″ | 2,684 |
25 pallets – 1.2×0.8m | |||||||
45 high 45’x8’x9’6″ |
24 pallets – 1.2×1.0m | 7′ 8 1″ | 8′ 5 12″ | 44′ 5 11″ | 7′ 8 9″ | 8′ 10 3″ | 3,036 |
27 pallets – 1.2×0.8m |
Container Type (feet/inches) |
Number of Pallets w/Dimensions |
Door Openings (mm) |
Internal Container Dimensions (mm) |
Volume (m3) |
|||
Width | Height | Length | Width | Height | |||
20 standard 20’x8’x8’6″ |
9 pallets – 1.2×1.0m | 2,339 | 2,274 | 5,896 | 2,350 | 2,393 | 33 |
11 pallets – 1.2×0.8m | |||||||
40 standard 40’x8’x8’6″ |
21 pallets – 1.2×1.0m | 2,340 | 2,274 | 12,032 | 2,350 | 2,393 | 67 |
25 pallets – 1.2×0.8m | |||||||
40 high 40’x8’x9’6″ |
21 pallets – 1.2×1.0m | 2,340 | 2,577 | 12,032 | 2,350 | 2,697 | 76 |
25 pallets – 1.2×0.8m | |||||||
45 high 45’x8’x9’6″ |
24 pallets – 1.2×1.0m | 2,340 | 2,585 | 13,556 | 2,352 | 2,698 | 85 |
27 pallets – 1.2×0.8m |
